System WV430 Storefront Window System

WV430

Configurations

Project-out • Casement-out

The WV430 storefront vent system is designed to be field glazed and installed with a minimal amount of labor. These vents are offered in two configurations: out-swing casements and project-out vents. Although the WV430 vent is designed to complement the flush glazed storefront, it may be glazed into any framing system with a flush surface opening and minimum frame depth of 3 1/2". The WV430 vent system is designed to incorporate many types of hardware configurations; including 4 bar hinge, multipoint locks, cam locks and roto-operators.

Features Benefits
Thermally broken frames Enhanced thermal performance
Designed to use with storefront systems Allows operable vent in fixed frames
Minimal additional metal sightline
Spans up to 1 1⁄8" wide glazing pocket Can be used in retrofit applications
Accommodates 1/4" & 1" glazing Energy savings options
Screens available Ventilation
Screen frames are extruded aluminum alloy Stronger more durable screens
Anodized and painted finishes available Multiple options to answer economic
and aesthetic concerns
Structural silicone glazed Reduces metal sightline at exterior
Designed to incorporate many types of hardware
configurations; including 4 bar hinge, multipoint
locks, cam locks and roto-operators
Provides design flexibility

For more information, contact your local sales representative at Kinstler and Associates, Inc.



System 8750XD 3" x 7 1/2" unitized Curtain Wall
with Duracast® fiberglass

XTherm® System 8750XD Unitized Curtain Wall and 875X Wall Vent

Configurations 875x

2 or 4-sided Captured/Pressure glazed • 2 or 4-sided structural silicone glazed

EFCo's 8750XD unitized Curtain Wall is the latest addition to our Xtherm® family of products. it utilizes Duracast® fiberglass composite technology in a patent pending thermal break design, which provides outstanding thermal performance without sacrificing structural integrity. the 8750XD offers an industry leading u-factor which is not compromised when the 875X Wall Vent is added. the combination of popular system profiles, dry glazed or 2 & 4 sided ssg, and integral vents, offers outstanding design and flexibility. While improved manufacturability with fewer parts and pieces, simplifies fabrication and ease of installation.

Features Benefits
3" Sightlines Commonly accepted profile
7-1/2" system depth Designed for 12 ft slab to slab spans
Patented Duracast® Thermal Break Provides industry leading U-Factor of .30
90º Inside and outside corners Allows for uninterrupted ribbons
Triple glazed performance with double glazing Less cost and weight
Integral vent options (875X) Tenant controlled ventilation
Dry glazed Reduced fabrication
U-Factor of .30 with .24 COG glass Industry leading thermal performance
Frame CRF of 82 Increased resistance to condensation
Rain screen design Minimum 15 lbs. water resistance
+/- 1/2" movement Allows for construction tolerance & movement
Estimated 45% reduction of fabrication Cost reduction
Up to 1-1/4" glazing infill Increased spandrel & vision glazing options
Thermal door frames Full system performance

For more information, contact your local sales representative at Kinstler and Associates, Inc.
